Solid Structure Vertical Shaft Kiln High Production Efficiency Easy Repair

Name: Solid Structure Vertical Shaft Kiln High Production Efficiency Easy Repair
Brand: ZK CORP
Price: 1 USD

Wholesale Solid Structure Vertical Shaft Kiln High Production Efficiency Easy Repair from china suppliers

Brand Name : ZK CORP

Model Number : Vertical Shaft Cement Kiln Plant

Certification : ISO,CE

Place of Origin : CHINA

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10 PER MONTH

Delivery Time : 30DAYS

Packaging Details : MEET THE SHIPPMENT REQUIRMENTS

Capacity : 50 - 500 (t/d)

Fuel : Mixed Fuel, Gas, Coal Powder

Limestone Size : 30~60 (mm) / 40~80 (mm)

Application : Lime production plant

Service : Design, Manufacturing, Sales etc

Limestone Size (mm) : 30~60/40~80

Heat Consumption (kJ/kg) : <4600

CaO (%) : >90

Activity (mL) : >300

Equipment Condition : New

Contact Now

Good Price Cement Turnkey Project Vertical Shaft Cement Kiln Plant

Description of Lime Vertical / Shaft Kiln:

Vertical Shaft Kiln to building material equipment, is the main equipment for sintering cement clinker in cement production plant, which can be divided into cement kiln, metallurgy chemical kiln and lime kiln according to different materials.
1. Cement Vertical Shaft Kiln is used for making of cement clinker and there are dry and wet methods to make cement.
2. Metallurgy chemical Vertical Shaft Kiln is used in metallurgy industry and ironworks for lean iron ore, chromium ore and ferronickel ore calcimine.
3. Lime Vertical Shaft Kiln is used in the most important equipment in lime production line.

Advantages Of Ours Kiln:

1. Solid structure, stable performance, high production efficiency.
2. Convenient operation, easy repair. Its energy consumption is reduced by 15% compared with the same kind of products.
3. The duration is far more than the same kind of products.
4. The stable performance and advanced structure have greatly improved its preheating effects.
5. Advanced processing technology, high cost performance ratio.
6. It can roast cement and metal ore with controllable temperature and wide application ranges.

Solid Structure Vertical Shaft Kiln High Production Efficiency Easy Repair

Parameter

Technical Parameters Of Vertical Klin (Mixed Fuel)
Capacity (t/d)	Effective Volume (m3)	Effective Height (m)	Effective Section Dia. (m)	Limestone Size (mm)	Heat Consumption (kJ/kg)	CaO (%)	Activity (mL)
100	98	20	Ø2.5	30~60/40~80	<4600	>90	>300
120	141	20	Ø3.0	30~60/40~80	<4600	>90	>300
150	202	21	Ø3.5	30~60/40~80	<4500	>90	>300
200	301	24	Ø4.0	30~60/40~80	<4500	>90	>300
300	397	25	Ø4.5	30~60/40~80	<4400	>90	>300
400	491	25	Ø5.0	30~60/40~80	<4200	>90	>300
500	735	26	Ø6.0	30~60/40~80	<4200	>90	>300
Remarks: All above data are for reference only.
Technical Parameters Of Vertical Lime Kiln (Fuel: Gas)
Capacity (t/d)	Effective Volume (m3)	Effective Height (m)	Effective Section Dia. (m)	Limestone Size (mm)	Heat Consumption (kJ/kg)	CaO (%)	Activity (mL)
50	70	20	Ø2.0	30~60/40~80	<4600	>90	>300
70	80	20	Ø2.5	30~60/40~80	<4600	>90	>300
80	100	20	Ø2.5	30~60/40~80	<4500	>90	>300
100	120	20	Ø2.7	30~60/40~80	<4500	>90	>300
120	140	20	Ø3.0	30~60/40~80	<4400	>90	>300
130	150	21	Ø3.0	30~60/40~80	<4200	>90	>300
150	200	20	2.5×4.5	30~60/40~80	<4200	>90	>300
Remarks: Above data are for reference only, and suitable for Vertical Kiln which use low heat fuel. Utilization coefficient of Vertical Kiln which use high heat fuel is higher.
